WatchGuard Rackmount Firebox Appliances
WatchGuard RackMount Firebox Appliances_規格比較表:
 |
 |
 |
 |
 |
 |
|
Model Name |
WatchGuard Firebox M290 |
WatchGuard Firebox M390 |
WatchGuard Firebox M590 |
WatchGuard Firebox M690 |
WatchGuard Firebox M4800 |
WatchGuard Firebox M5800 |
Ideal For |
75 Users |
250 Users |
500 Users |
850 Users |
2500 Users |
7500 Users |
Performance |
||||||
UTM (Full Scan) |
1180 Mbps |
2.4 Gbps |
3.3 Gbps |
4.6 Gbps |
5.2 Gbps |
11.3 Gbps |
Firewall (UDP 1518) |
5.8 Gbps |
18 Gbps |
20 Gbps |
29.7 Gbps |
49.6 Gbps |
87 Gbps |
VPN (UDP 1518) |
2.4 Gbps |
5.2 Gbps |
6.84 Gbps |
10.0 Gbps |
16.4 Gbps |
18.8 Gbps |
VPN (IMIX) |
800 Mbps |
1.8 Gbps |
2.2 Gbps |
3.2 Gbps |
4.8 Gbps |
5.2 Gbps |
AntiVirus |
1.47 Gbps |
3.1 Gbps |
5.0 Gbps |
6.2 Gbps |
12.5 Gbps |
22 Gbps |
IPS (Full Scan) |
1.3 Gbps |
3.3 Gbps |
4.6 Gbps |
5.8 Gbps |
8.1 Gbps |
12.5 Gbps |
HTTPS (Full Scan) |
696 Mbps |
1.32 Gbps |
1.9 Gbps |
2.9 Gbps |
3 Gbps |
4.9 Gbps |
VPN Tunnels |
||||||
Branch Office VPN Tunnels |
75 |
250 |
500 |
1000 |
5,000 |
Unrestricted |
Mobile VPN |
75 |
250 |
500 |
1000 |
10,000 |
Unrestricted |
Hardware |
||||||
Interfaces & Modules |
Included: 8x1Gb copper; Optional: 8x1Gb copper, 4x1Gb copper, 4x1Gb SFP fiber, 2x10Gb SFP+ fiber, 4x5Gb copper multispeed |
Included: 8x1Gb copper; Optional: 8x1Gb copper, 4x1Gb copper, 4x1Gb SFP fiber, 2x10Gb SFP+ fiber, 4x5Gb copper multispeed |
Included: 8x1Gb copper, 2x10 Gb SFP+ fiber; Optional: 8x1Gb copper, 4x1Gb copper, 4x1Gb SFP fiber, 2x10Gb SFP+ fiber, 4x5Gb copper multispeed with PoE+ |
Included: 8x1Gb copper, 2x10Gb SFP+ fiber, 2x10Gb copper multispeed; Optional: 8x1Gb copper, 4x1Gb copper, 4x1Gb SFP fiber, 2x10Gb SFP+ fiber, 4x5Gb copper multispeed with PoE+ |
8x1Gb (included); Optional 8x1Gb, 8x1Gb fiber, 4x10Gb fiber, 2x40Gb fiber |
8x1Gb, 4x10Gb fiber (included); Optional 8x1Gb, 8x1Gb fiber, 4x10Gb fiber, 2x40Gb fiber |
Wireless Models |
N/A |
N/A |
N/A |
N/A |
N/A |
N/A |
Networking Features |
||||||
VLAN |
100 |
250 |
750 |
1000 |
1000 |
Unrestricted |
SD-WAN Dynamic Path Selection |
✔ |
✔ |
✔ |
✔ |
✔ |
✔ |
